WSQ Apply Geometric Dimensioning & Tolerancing at Intermediate Level (GD&T)
- Post-Secondary (Non-Tertiary): General & Vocational
Application procedures
All applications are to be submitted (with full documentation) via email (enquiry@atts-asia.com) at least 7 working days prior to course commencing date. Successful applicants will receive the course confirmation and payment advisory email. Registration is only confirmed upon full payment of course fees.
- Appreciate the benefits of GD&T and the limitations of plus and minus dimensioning;
- Understand the general rules of GD&T;
- Understand the practices for expressing tolerances for mating parts using limits and fits;
- Understand the symbols for specifying geometric characteristics and other dimensional requirements on engineering drawings;
- Interpret the effect of modifiers on geometric tolerance values and calculate applicable tolerances,
- Understand virtual condition boundary and resultant condition boundary;
- Identify features as datum features and establish datums and datum reference frames.
- Apply GD&T to control the form, orientation, location, profile, and runout of features;
- Apply inspection techniques for GD&T control.
Certification
Statement of Attainment (SOA) issued by (SSG)
This course is designed for employees who need formal GD&T training to build foundational knowledge and skills to perform their jobs effectively.
- GD&T Introduction
- General Rules
- Tolerancing Methods
- Definitions & Concepts
- Material Condition Modifiers
- Virtual Condition & Feature Control Frames
- Datums: Theory-to-Reality
- Position Tolerancing
- Form Controls
- Orientation Controls
- Profile Controls
- Runout Controls
- Concentricity/Symmetry Controls
- Geometric Design Process
Course duration
05 Days
Assessment
Written Assessment – This assessment will constitute 50% of the final grade.
Problem / Scenario based Assessment – This assessment will constitute 50% of the final grade.
